Finishing, Deburring, Grinding, Sanding
Built for high production during multiple shifts, the Timesavers’ 4100 & 4200 series is heavy-duty for when the workload is demanding, deadlines are tight, and your machinery needs to be absolutely dependable.
Features
Series 4100 (Puma)
Engineered, designed, and built for 3 shifts and 24/7 operations. This high-quality grinder is available with up to 4 heads with multiple head types. This makes the machine extremely suitable for machining thin, oiled, greasy, and/or highly flammable metal parts and materials. Pictured above.
- Specs
- Number of heads: 1-4
- Head types: Drum, Brush
- 75″ sanding belt length
- 10″ minimum part length
- Up to 30 HP main motors
- 8″ diameter barrel brush
- 0-6″ opening
- Machine widths of 37″ & 52″
- 15-45 fpm throughput
- Electronic photo tracking eyes for accurate abrasive belt tracking
- Application
- Integrated filtration system to keep metal parts cool during machining
- Added lubricity ensures the life f the abrasive belt
- High-pressure air system dries the metal parts as they are exit the machine
- Removal of burrs on laser, water-jet, punched, and cut metal parts.
- Provide the finest finish in the industry
- Multiple configurations available based on customer applications
- Deburr, edge break, & finishing of metal in one pass
- Mixing of metals, including titanium, aluminum, carbon & stainless steel, copper, etc.
Series 4200
The ultimate dry, rotary brush for deburring, finishing, edge radiussing, laser oxide removal, and heavy slag removal. The perfect solution for manufacturers who supply premium quality products, are running three shifts, have heavy production, or need a custom-built modular machine.
- Specs
- Number of heads: 1-5
- Head types: Drum – Rotary Brush – Hammerhead
- Machine widths: 52″ (1350mm), 63″ (1600mm)
- HMI Siemens controller
- 0-4″ bed opening
- A/C frequency controlled widebelt, brushes, & carousel
- 8 brushes – 14″ brush diameter (quick-change system)
- Produce an edge radius of 2mm/0.080″
- 7″, 11″, & 18″ contact roller diameter
- Vacuum bed for small parts
- Brush life up to 3,000 hours
- Multi-directional rotary brush assembly
- U.L. Certified
- Application
- Processes punched, laser-cut, plasma cut, 3D, or milled parts with deep pockets
- Removal of burrs on laser, plasma, water-jet cut parts
- Can be integrated into an Industry 4.0/Smart Industry software platform
- Uniform and controllable side radius for the aerospace, catering, medical industries, & more
- Deburring of multiple alloys, vinyl, PVC, and coated parts
- Totally customizable based on your application
- Dry operation
